Cisco Catalyst 6500 Series 10 Gigabit Ethernet modules Specifications

● Occupies one slot in the Cisco Catalyst 6500 Series chassis or Cisco 7600 Series chassis

● Dimensions (H x W x D): 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm)

● Weight:

◦ Cisco Catalyst 6708 and 6716: 13 pounds excluding X2 components; ¼ pound for each X2

◦ Cisco Catalyst 6704: 10 pounds excluding XENPAK and DFC components; 2/3 pound for each XENPAK

Operating temperature:

● Agency-certified for operation: 32 to 104°F (0 to 40°C)

● Design and tested for operation 32 to 130°F (0 to 55°C)

● Storage temperature: –40 to 167°F (–40 to 75°C)

● Relative humidity: 10 to 90 percent, noncondensing

Operating altitude:

● Agency-certified for operation: –500 to 6500 ft (–150 to 2000m)

● Designed and tested for operation –500 to 10000 ft (–150 to 3000m)

Cisco Catalyst 6500 Series 10 Gigabit Ethernet modules, when installed in a system, comply with the following EMC and safety standards:

EMC Standards:

● FCC Part 15 (CFR 47) Class A

● ICES-003 Class A

● VCCI Class A

● EN55022 Class A

● EN55024

● CISPR24

● CISPR 22 Class A

● AS/NZS CISPR 22 Class A

● ETS 300 386

● KN 22 Class A

● EN 50082-1

● EN61000-3-2

● EN61000-3-3

● EN61000-6-1

● CNS13438 Class A

● KN6100 -4 Series

Safety Standards:

● UL 60950-1

● CAN/CSA C22.2 No. 60950

● EN 60950-1

● IEC 60950-1

● AS/NZS 60950-1

● IEC 60825 Class 1

● EN 60825 Class 1

● 21CFR 1040

● ETS 300 019-2-1, Class 1.1 Storage

● ETS 300 019-2-2, Class 2.1 and 2.2 Transportation

● ETS 300 019-2-3, Class 3.1E Stationary Use

● ETHERLIKE-MIB (RFC 1643)

● IF-MIB (RFC 1573)

● Bridge MIB (RFC 1493)

● CISCO-STACK-MIB

● CISCO-VTP-MIB

● CISCO-CDP-MIB

● RMON MIB (RFC 1757)

● CISCO-PAGP-MIB

● CISCO-STP-EXTENSIONS-MIB

● CISCO-VLAN-BRIDGE-MIB

● CISCO-VLAN-MEMBERSHIP-MIB

● ENTITY-MIB (RFC 2037)

● HC-RMON

● RFC1213-MIB (MIB-II)

● SMON-MIB

● WS-X6716-10T-3C: 509.3W (12.1A @ 42V)

● WS-X6716-10T-3CXL: 538.7W (12.8A @ 42V)

● WS-X6716-10G-3C: 457.8W (10.9A @ 42V)

● WS-X6716-10G-3CXL: 487.2W (11.6A @ 42V)

● WS-X6708-10G-3C: 444.36W (10.58A @ 42v)

● WS-X6708-10G-3CXL: 473.76w (11.28A @ 42V)

● WS-X6704-10GE with DFC3CXL: 362.46W (8.63A @ 42V)

● WS-X6704-10GE with DFC3C: 333.06W (7.93A @ 42V)

● WS-X6704-10GE with DFC3BXL: 402.36W (9.58A @ 42V)

● WS-X6704-10GE with DFC3B: 377.16W (8.98A @ 42V)

● WS-X6704-10GE with DFC3A: 389.76W (9.28A @ 42V)

● WS-X6704-10GE with CFC: 295.26W (7.03A @ 42V)

● Status: green (operational), red (faulty), and orange (module booting)

● Link: green (port enabled and connected), orange (port disabled), and off (port enabled and not connected)
